Makita XRH04Z 18V LXT 7/8" SDS-Plus Rotary Hammer (Tool Only)

Lithium_Ion Brushless Cordless

The Makita 18V LXT Lithium-Ion Cordless 7/8" SDS-PLUS Rotary Hammer (model XRH04Z, tool only) delivers faster, more efficient percussive drilling to the job site. The versatile XRH04Z has 3-mode operation and a built-in torque limiter to ensure stable torque control for a range of concrete drilling tasks, with a more compact design and less vibration.

The XRH04Z features a Makita-built high torque motor that delivers 0-1,200 RPM, 0-4,000 blows per minute (BPM), and 1.4 ft.lbs. of impact energy for a wide range of concrete drilling applications. The 3-mode switch allows for hammering, rotation, or hammering with rotation. It also delivers two-times faster drilling with synchronized RPM and BPM for more efficient drilling. The built-in torque limiter clutch disengages if the bit jams, and ensures more stable torque control.

Standard Equipment:

• (1) Cordless SDS-Plus Rotary Hammer (XRH04Z)
• (1) Side Handle (158057-6)
• (1) Depth Gauge (234219-0)

Specifications:

• Tool Rating: 18 Volt
• No Load Speed (variable speed): 0 to 1,250 RPM
• Blows Per Minute (variable speed): 0 to 4,000 BPM
• Bit Type: Accepts SDS-PLUS
• Max. Capacity (concrete drilling): 7/8"
• Optimum Range (concrete drilling): 5/32" to 1/2"
• Impact Energy (Joules): 2.0 J
• Impact Energy (ft-lbs): 1.5
• Vibration (m/s²): 12.5
• Bind-Up Control: No
• Overall Length: 16-3/8"
• Weight (with battery): 8.8 lbs

Features:

• Makita-built variable speed motor delivers 0-1,200 RPM and 0-4,000 BPM
• 3-mode operation for "Rotation Only", "Hammering with Rotation" or "Hammering Only" for multiple applications
• Torque limiting clutch engineered to prevent gear damage by automatically disengaging gears if the bit binds
• Faster drilling with synchronized RPM and BPM
• Job site tested shock absorbent handle protects the battery housing for extra durability
• One-touch sliding chuck for quick bit changes
• Chisel rotates 360° with 40 different positions
• Compact and ergonomic design at only 16-3/8" long
• Weighs only 7.7 lbs. with battery (battery not included) for reduced operator fatigue
• Large 2-finger variable speed trigger for added convenience
• Rubberized soft grip handle provides increased comfort on the job
• Electric brake allows the tool to be repositioned faster for maximum productivity
• Equipped with Star Protection Computer Controls to protect against overloading, over-discharging and over-heating
• Rapid Optimum Charger communicates with the battery's built-in chip throughout the charging process to optimize battery life by actively controlling current, voltage and temperature (battery and charger sold separately)
• Rapid Optimum Charger has a built-in fan to cool the battery for faster, more efficient charging (battery and charger sold separately)
• Makita technology delivers category-leading charge time, so the battery spends more time working and less time sitting on the charger (battery and charger sold separately)
• Compatible with Makita 18V Lithium-Ion batteries with a Star symbol (battery sold separately)
• 3-year limited warranty
